WATER PUMP SIMCA 1000 2nd Model

Water pump for SIMCA 1000 2nd model

Height of the fixing body: 128mm

Inlet and outlet outside diameter: 32mm

Heating outer diameter: 25mm

Original reference: OEM: 0058465000

Vehicle allocation:

SIMCA:

1000: 2nd model, all engines except engine 315:

SIM '4: S1 EA, engine 359, 4hp, 777cc, 68x53.5 from 1969 to 1972

1000, 1005, Gl, GLS, GLE: S1 EB 1, 349 S engine, 5hp, 944cc, 68x55 from 1968

1000, 1006, LS, GLS, Special: S1 EC 1, engine 351, 6hp, 1118cc, 74x65 from 1969

1000 Rally: S1 EC 1, engine 351, 6hp, 1118cc, 74x65 from 1970

1001 Rallye I: S1 HE 1, engine 371, 1G1, 7hp, 1294cc, 76.7x70 from 1972

1000 Rally II and III: S1 JC 1, engine 1G4, 7hp, 1294cc, 76.7x70 Rally II from 1973, Rally III from 1978

1200 S

CG

ASSEMBLY INFORMATION:

First and foremost install without constraint (do not tap with a hammer for example to drive the pulley on the shaft) the water pump drive pulley (belt pulley).

Proceed immediately after torque tightening of the supplied lock nut. Once the pulley is in place and tightened, install the fan bellows holder and the cooling turbine also without constraint, then torque tighten the supplied lock nut.

If the mounting direction is not respected, there will be a risk of leakage due to the breakage of one of the seals inside the water pump.
