WATER PUMP SIMCA 1000 1st Model, Motor 315

Water pump for SIMCA 1000 with motor 315

Height of the fixing body: 100mm

Inlet and outlet outside diameter: 29mm

Heating outside diameter: 17mm

Original reference: OEM: 24737L

Vehicle allocation:

SIMCA:

1000: 315 engine

1000 Bertone Coupé

ASSEMBLY INFORMATION:

First and foremost install without constraint (do not tap with a hammer for example to drive the pulley on the shaft) the water pump drive pulley (belt pulley).

Proceed immediately after torque tightening of the supplied lock nut. Once the pulley is in place and tightened, install the fan bellows holder and the cooling fan also without constraint, then torque tighten the supplied lock nut.

If the mounting direction is not respected, there will be a risk of leakage due to the breakage of one of the seals inside the water pump.
